Recording – Introducing Azure Virtual WAN

Here is a video recording that I recorded last week called Introducing Azure Virtual WAN.

I was scheduled to do a live presentation for the (UK) Northern Azure User Group (NAUG). All was looking good … until my wife went into labour 5 weeks early! We welcomed healthy twin girls and my wife is doing well – all are home now. But at the time, I was clocking up lots of miles to visit my wife and new daughters in the evening. The scheduled online user group meeting was going to clash with one of my visits.

I reached out to the organiser, Matthew Bradley (a really good and smart guy – and someone who should be an MVP IMO), and explained the situation. I offered to record my presentation for the user group. So that’s what I did – I deliberately did a 1-take recording and didn’t do the usual editing to clean up mistakes, coughs, actually’s and hmms. I felt that the raw recording would be more like what I would be like if I was live.

The feedback was positive and I was asked if I would share the video. So here you go:

An Introduction to Azure ExpressRoute Architecture

This post will give you an overview of Azure ExpressRoute architecture. This is not a “how to” post; instead, the purpose of this post is to document the options for architecting connectivity with Microsoft Azure in one concise (as much as possible) document.

Introduction to ExpressRoute

Azure ExpressRoute is a form of private Layer-2 or Layer-3 network connectivity between a customer’s on-premises network(s) and a virtual network hosted in Microsoft Azure. ExpressRoute is one of the 2 Azure-offered solutions (also, VPN) for achieving a private network connection.

There are 2 vendor types that can connect you to Azure using ExpressRoute:

  • Exchange provider: Has an ExpressRoute circuit in their data centre. Either you run your “on-premises” in their data centre or you connect to their data centre.
  • Network service provider: You get a connection to an ISP and they relay you to a Microsoft edge data centre or POP.

The locations of ExpressRoute and Azure are often confused. A connection using ExpressRoute, at a very high level and from your perspective, has three pieces:

  • Circuit: A connection to a Microsoft edge data centre or pop. This can be one of many global locations that are often nothing to do with Azure regions; they are connected to the same Microsoft WAN as Azure (and Microsoft 365) and are a means to relay you to Azure (or Microsoft 365) using Azure ExpressRoute.
  • Connection: Connecting an Azure Virtual Network (ExpressRoute Gateway) in an Azure region to a circuit that terminates at the edge data centre or POP.
  • Peering: Configuring the routing across the circuit and connection.

For example, a customer in Eindhoven, Netherlands might have an ExpressRoute circuit that connects to “Amsterdam”; This POP or edge data centre is probably in Amsterdam, Netherlands, or the suburbs. The customer might use that circuit to connect to Azure West Europe, colloquially called “Amsterdam”, but is actually in Middenmeer, approximately 60 KM north of Amsterdam.

ExpressRoute Versus VPN

The choice between ExpressRoute and site-to-site VPN isn’t always as clear-cut as one might think: “big organisations go with ExpressRoute and small/mid go with VPN”. Very often, organisations are choosing to access Azure services over the Internet using HTTPS, with small amounts of legacy traffic traversing a private connection. In this case, VPN is perfect. But when you want an SLA or low latency, ExpressRoute is your choice.

Site-to-Site VPN ExpressRoute
Microsoft SLA Microsoft: Azure

Internet: No one

Microsoft: Azure

Service Provider: Circuit

Max bandwidth Aggregate of 10 Gbps 100 Gbps
Routing BGP (even if you don’t use/enable it) BGP
Latency Internet Low
Multi-Site See SD-WAN (Azure Virtual WAN) Global Reach

Also see Azure Virtual WAN

Connections Azure Virtual Networks Azure Virtual Networks

Other Azure Services

Microsoft 365

Dynamics 365

Other clouds, depending on service provider

Payment Outbound data transfer and your regular Internet connection Payment to service provider for the circuit.

Payment for either a metered (outbound data + circuit) or unlimited data (circuit) to Microsoft.

Terminology

  • Customer premises equipment (CPE) or Customer edge routers (CEs): 2, ideally, edge devices that will be connected in a highly available way to 2 lines connecting your network(s) to the service provider.
  • Provider edge routers (PEs), CE facing: Routers or switches operated by the service provider that the customer is connected to.
  • Provider edge routers (PEs), MSEE facing: Routers or switches operated by the service provider that connect to Microsoft’s MSEEs.
  • Microsoft Enterprise Edge (MSEE) routers: Routers in the Microsoft POP or edge data centre that the service provider has connected to.

The MSEE is what:

  • Your ExpressRoute virtual network gateway connects to.
  • Propagates BGP routes to your virtual network.
  • Can connect two virtual networks together (with BGP propagation) if they both connect to the same circuit (MSEE).
  • Can relay you to other Azure services or other Microsoft cloud services.

It is very strongly recommended that the customer deploys two highly available pieces of hardware for the CEs. The ExpressRoute virtual network gateway is also HA, but if the Azure region supports it, spread the two nodes across different availability zones for a higher level of availability.

FYI, these POPs or Edge Data Centers also host other Azure services for edge services.

Peering

Quite often, the primary use case for Azure ExpressRoute is to connect to Azure virtual networks, and resources connected to those virtual networks such as:

  • Virtual machines
  • VNet integrated SKUs such as App Service Environment, API Management, and SQL Managed Instance
  • Platform services supporting Private Endpoint

That connectivity is provided by Azure Private Peering. However, you can also connect to other Microsoft services using Microsoft Peering:

To use Microsoft Peering you will need to configure NAT to convert connections from private IP addresses to public IP addresses before they enter the Microsoft network.

ExpressRoute And VPN

There are two scenarios where ExpressRoute and site-to-site VPN can coexist to connect the same on-premises network and virtual network.

The first is for failover. If you deploy a /27 or larger GatewaySubnet then that subnet can contain an ExpressRoute Virtual Network Gateway and a VPN Virtual Network Gateway. You can then configure ExpressRoute and VPN to connect the same on-premises and Azure networks. The scenario here is that the VPN tunnel will be an automated failover connection for the ExpressRoute circuit – failover will happen automatically with less than 10 packets being lost. Two things immediately come to mind:

  • Use a different ISP for Internet/VPN connection than used for ExpressRoute
  • Both connections must propagate the same on-premises networks.

An interesting new twist was announced recently for Virtual Network Gateway and Azure Virtual WAN. By default, there is no encryption on your ExpressRoute circuit (more on this later). You will be able to initiate a site-to-site VPN connection across the ExpressRoute circuit to a VPN Virtual Network Gateway that is in the same GatewaySubnet as the ExpressRoute Virtual Network Gateway, encrypting your traffic.

ExpressRoute Tiers

There are three tiers of ExpressRoute circuit that you can deploy in Microsoft Azure. I have not found a good comparison table, so the below will not be complete:

Standard Premium
Price Normal More Expensive
Azure Virtual WAN support Announced, not GA GA
Azure Global Reach Limited to same geo-zone All regions
Max connections per circuit 10 100, depending on the circuit size (Mbps) – 20 for 50 Mbps, 100 for 10 Gbps+
Connections from different subscriptions No Yes
Max routes advertised Private peering: 4,000

Microsoft peering: 200

Private Peering: Up to 10,000

Microsoft peering: 200

I said “three tiers”, right? But there is also a third tier called Local which is very lightly documented. ExpressRoute Local is a subset of ExpressRoute Standard where:

  • The circuit can only connect to 1 or 2 Azure regions in the same metro as the POP or edge data centre. Therefore it is available in fewer locations than ExpressRoute Standard.
  • ExpressRoute Global Reach is not available.
  • It requires an unlimited data plan with at least 1 Gbps, coming in at ~25% of the price of a 1 Gbps Standard tier unlimited data plan.

Service Provider Types

There are three ways that a service provider can connect you to Azure using ExpressRoute, with two of them being:

  • Layer-2: A VLAN is stretched from your on-premises network to Azure
  • Layer-3: You connect to Azure over IP VPN or MPLS VPN. Your on-premises network connects either by BGP or a static default route.

There is a third option, called ExpressRoute Direct.

ExpressRoute Direct

A subset of the Microsoft POPs or edge data centres offer a third kind of connection for Azure ExpressRoute called ExpressRoute Direct. The features of this include:

  • Larger sizes: You can have sizes from 1 Gbps to 100 Gbps for massive data ingestion, for things like Cosmos DB or storage (HPC).
  • Physical Isolation: Some organisations will have a compliance reason to avoid connections to shared network equipment (the CEs and MSEE).
  • Granular control of circuit distribution: Based on business unit

This is a very specialised SKU that you must apply to use.

ExpressRoute FastPath

The normal flow of packets routing into Azure over ExpressRoute is:

  1. Enter Microsoft at the MSEE
  2. Travel via the ExpressRoute Virtual Network Gateway.
  3. If a route table exists, follow that route, for example, to a hub-based firewall.
  4. Route to the NIC of the virtual machine

There is a tiny latency penalty by routing through the Virtual Network Gateway. For a tiny percentage of customers, this latency may cause issues.

The concept of ExpressRoute Fast Path is that you can skip the hop of the virtual network gateway and route directly to the NICs of the virtual machines (in the same virtual network as the gateway).

To use this feature you must be using one of these gateway sizes:

  • Ultra Performance
  • ErGw3AZ

The following are not supported and will force traffic to route via the ExpressRoute Virtual Network Gateway:

  • There is a UDR on the GatewaySubnet
  • Virtual Network Peering is used. An alternative is to connect the otherwise-peered VNets directly to the circuit with their own VNet Gateway.
  • You use a Basic Load Balancer in front of the VMs; use a Standard tier Load Balancer.
  • You are attempting to connect to Private Endpoint.

ExpressRoute Global Reach

I think that ExpressRoute Global Reach is one of the more interesting features in ExpressRoute. You can have two or more offices, each with their own ExpressRoute (not Local tier) circuit to a local POP/edge data center, and enable Global Reach to allow:

  • The offices to connect to Azure/Microsoft cloud resources
  • Connect to each other over the Microsoft WAN instead of deploying a WAN

Note that ExpressRoute Standard will support connecting locations in the same geo-zone, and ExpressRoute Premium will support all geo-zones. Supported POPs are limited to a small subset of locations.

Encryption

Traffic over ExpressRoute is not encrypted and as Edward Snowden informed us, various countries are doing things to sniff traffic. If you wish to protect your traffic you will have to “bring your own key”.  We have a few options:

  • The aforementioned VPN over ExpressRoute, which is available now for Virtual Network Gateway and Azure Virtual WAN.
  • Implement a site-to-site VPN across ExpressRoute using a third-party virtual appliance hosted in the Azure VNet.
  • IPsec configured on each guest OS, limited to machines.
  • MACsec, a Layer-2 feature where you can implement your own encryption from your VE to the MSEE, encrypting all traffic, not just to/from VMs.

The MACsec key is stored securely in Azure Key Vault. From what I can see, MACsec is only available on ExpressRoute Direct. Microsoft claims that it does not cause a performance issue on their routers, but they do warn you to check your CE vendor guidance.

Multi-Cloud

Now you’ll see why I talked about Layer-2 and Layer-3. Depending on your service provider type and their connectivity to non-Microsoft clouds, if you have a circuit with the service provider (from your CEs to their CE facing PEs) that same circuit can be used to connect to Azure over ExpressRoute and to other clouds such as AWS or others. With BGP propagation, you could route from on-premises to/from either cloud, and your deployments in those clouds could route to each other.

Bidirectional Forwarding Detection (BFD)

The circuit is deployed as two connections, ideally connected to 2 CEs in your edge network. Failover is automated, but some will want failover to be as quick as possible. You can reduce the BGP keepalive and hold-time but this will be processor intensive on the network equipment.

A feature called BFD can detect link failure in a sub-second with low overhead. BFD is enabled on “newly” created ExpressRoute private peering interfaces on the MSEEs – you can reset the peering if required. If you want this feature then you need to enable it on your CEs – the service provider must also enable it on their PEs.

Monitoring

Azure Monitor provides a bunch of metrics for ExpressRoute that you can visualise or create alerts on.

Azure’s Connection Monitor is the Microsoft-offered solution for monitoring an ExpressRoute connection. The idea is that a Log Analytics agent (Windows or Linux) is deployed onto one or more always-on on-premises machines. A test is configured to run across the circuit measuring availability and performance.



Monitoring & Alerting for Windows Defender in Azure VMs

In this post, I will explain how one can monitor Windows Defender and create incidents for it with Azure VMs.

Background

Windows Defender is built into Windows Server 2016 and Windows Server 2019. It’s free and pretty decent. But it surprises me how many of my customers (all) choose Defender over third-parties for their Azure VMs … with no coaching/encouragement from me or my colleagues. There is an integration with the control plane using the antimalwareagent extension. But the level of management is poor-none. There is a Log Analytics solution, but solutions are deprecated and, last time I checked, it required the workspace to be in per-node pricing mode. So I needed something different to operationalise Windows Defender with Azure VMs.

Data

At work, we always deploy the Log Analytics extension with all VMs – along with the antimalware extension and a bunch of others. We also enable data collection in Azure Security Center. We use a single Log Analytics workspace to enable the correlation of data and easy reporting/management.

I recently found out that a table in Log Analytics called ProtectionStatus contains a “heartbeat” record for Windows Defender. Approximately every hour, a record is stored in this table for every VM running Windows Defender. In there, you’ll find some columns such as:

  • DeviceName: The computer name
  • ThreatStatusRank: A code indicating the health of the device according to defender:
    • 150: Health
    • 470: Unknown (no extension/Defender)
    • 350: Quarantined malware
    • 550: Active malware
  • ThreatStatus: A description for the above code
  • ThreatStatusDetails: A longer description
  • And more …

So you can see that you can search this table for malware infection records. First thing, though, is to filter out the machines/records reporting that there is no Defender (Linux machines, for example):

let all_windows_vms =
Heartbeat
| where TimeGenerated > now(-7d)
| where OSType == 'Windows'
| summarize makeset(Resource);
ProtectionStatus
| where Resource in (all_windows_vms)
| sort by TimeGenerated desc

The above will find all active Windows VMs that have been reporting to Log Analytics via the extension heartbeat. Then we’ll store that data in a set, and search that set. Now we can extend that search, for example finding all machines with a non-healthy state (150):

let all_windows_vms = Heartbeat
| where TimeGenerated > now(-7d)
| where OSType == 'Windows'
| summarize makeset(Resource);
ProtectionStatus
| where Resource in (all_windows_vms)
| where ThreatStatusRank <> 150
| sort by TimeGenerated desc

Testing

All the tech content here will be useless without data. So you’ll need some data! Search for the Eicar test string/file and start “infecting” machines – be sure to let people know if there are people monitoring the environment first.

Security Center

Security Center will record incidents for you:

You will get email alerts if you have configured notifications in the subscription’s Security Center settings. Make sure the threshold is set to LOW.

If you want an alternative form of alert then you can use a Log Analytics alert (Scheduled Query Alert resource type) based on the below basic query:

SecurityAlert
| where TimeGenerated > now(-5m)
| where VendorName == 'Microsoft Antimalware'

The above query will search for Windows Defender alerts stored in Log Analytics (by Security Center) in the last 5 minutes. If the threshold is freater than 0 then you can trigger an Azure Monitor Action Group to tell whomever or start whatever task you want.

Workbooks

Armed with the ability to query the ProtectionStatus table, you can create your own visualisations for easy reporting on Windows Defender across many machines.



The pie chart is made using this query:

let all_windows_vms =
Heartbeat
| where TimeGenerated > now(-7d)
| where OSType == 'Windows'
| summarize makeset(Resource);
ProtectionStatus
| where TimeGenerated > now(-7d)
| where Resource in (all_windows_vms)
| where ThreatStatusRank <> '150'
| summarize count(Threat) by Threat

With some reading and practice, you can make a really fancy workbook.

Azure Sentinel

I have enabled the Entity Behavior preview.

Azure Sentinel is supposed to be the central place to monitor all security events, hunt for issues, and where to start investigations – that latter thanks to the new Entity Behavior feature. Azure Sentinel is powered by Log Analytics – if you have data in there then you can query that data, correlate it, and do some clever things.

We have a query that can search for malware incidents reported by Windows Defender. What we will do is create a new Analytic Rule that will run every 5 minutes using 5 minutes of data. If the results exceed 0 (threshold greater than 0) then we will create an incident.

let all_windows_vms =
Heartbeat
| where TimeGenerated > now(-7d)
| where OSType == 'Windows'
| summarize makeset(Resource);
ProtectionStatus
| where TimeGenerated > now(-5m)
| where Resource in (all_windows_vms)
| where ThreatStatus <> 'No threats detected' or ThreatStatusRank <> '150' or Threat <> ''
| sort by Resource asc
| extend HostCustomEntity = Computer

The last line is used to identity an entity. Optionally, we can associate a logic app for an automated response. Once that first malware detection is found:

You can do the usual operational stuff with these incidents. Note that this data is recorded and your effectiveness as a security organisation is visible in the Security Efficiency Workbook in Azure Sentinel – even the watchers are watched! If you open an incident you can click investigate which opens a new Investigation screen that leverages the Entity Behavior data. In my case, the computer is the entity.

The break-out dialogs allow me to query Log Analytics to learn more about the machine and its state at the time and the state of Windows Defender. For example, I can see who was logged into the machine at that time and what processes were running. Pretty nice, eh?



Azure App Service, Private Endpoint, and Application Gateway/WAF

In this post, I will share how to configure an Azure Web App (or App Service) with Private Endpoint, and securely share that HTTP/S service using the Azure Application Gateway, with the optional Web Application Firewall (WAF) feature. Whew! That’s lots of feature names!

Background

Azure Application (App) Services or Web Apps allows you to create and host a web site or web application in Azure without (directly) dealing with virtual machines. This platform service makes HTTP/S services easy. By default, App Services are shared behind a public/ & shared frontend (actually, load-balanced frontends) with public IP addresses.

Earlier this year, Microsoft released Private Link, a service that enables an Azure platform resource (or service shared using a Standard Tier Load Balancer) to be connected to a virtual network subnet. The resource is referred to as the linked resource. The linked resource connects to the subnet using a Private Endpoint. There is a Private Endpoint resource and a special NIC; it’s this NIC that shares the resource with a private IP address, obtained from the address space of the subnet. You can then connect to the linked resource using the Private Endpoint IPv4 address. Note that the Private Endpoint can connect to many different “subresources” or services (referred to as serviceGroup in ARM) that the linked resource can offer. For example, a storage account has serviceGroups such as file, blob, and web.

Notes: Private Link is generally available. Private Endpoint for App Services is still in preview. App Services Premium V2 is required for Private Endpoint.

The Application Gateway allows you to share/load balance a HTTP/S service at the application layer with external (virtual network, WAN, Internet) clients. This reverse proxy also offers an optional Web Application Firewall (WAF), at extra cost, to protect the HTTP/S service with the OWASP rule set and bot protection. With the Standard Tier of DDoS protection enabled on the Application Gateway virtual network, the WAF extends this protection to Layer-7.

Design Goal

The goal of this design is to ensure that all HTTP/S (HTTPS in this example) traffic to the Web App must:

  • Go through the WAF.
  • Reverse proxy to the App Service via the Private Endpoint private IPv4 address only.

The design will result in:

  • Layer-4 protection by an NSG associated with the WAF subnet. NSG Traffic Analytics will send the data to Log Analytics (and optionally Azure Sentinel for SIEM) for logging, classification, and reporting.
  • Layer-7 protection by the WAF. If the Standard Tier of DD0S protection is enabled, then the protection will be at Layer-4 (Application Gateway Public IP Address) and Layer-7 (WAF). Logging data will be sent to Log Analytics (and optionally Azure Sentinel for SIEM) for logging and reporting.
  • Connections directly to the web app will fail with a “HTTP Error 403 – Forbidden” error.

Note: If you want to completely prevent TCP connections to the web app then you need to consider App Service Environment/Isolated Tier or a different Azure platform/IaaS solution.

Design

Here is the design – you will want to see the original image:

There are a number of elements to the design:

Private DNS Zone

You must be able to resolve the FQDNs of your services using the per-resource type domain names. App Services use a private DNS zone called privatelink.azurewebsites.net. There are hacks to get this to work. The best solution is to create a central Azure Private DNS Zone called privatelink.azurewebsites.net.

If you have DNS servers configured on your virtual network(s), associate the Private DNS Zone with your DNS servers’ virtual network(s). Create a conditional forwarder on the DNS servers to forward all requests to privatelink.azurewebsites.net to 168.63.129.16 (https://docs.microsoft.com/en-us/azure/virtual-network/what-is-ip-address-168-63-129-16). This will result in:

  1. A network client sending a DNS resolution request to your DNS servers for *.privatelink.azurewebsites.net.
  2. The DNS servers forwarding the requests for *.privatelink.azurewebsites.net to 168.63.129.16.
  3. The Azure Private DNS Zone will receive the forwarded request and respond to the DNS servers.
  4. The DNS servers will respond to the client with the answer.

App Service

As stated before the App Service must be hosted on a Premium v2 tier App Service Plan. In my example, the app is called myapp with a default URI of https://myapp.azurewebsites.net. A virtual network access rule is added to the App Service to permit access from the subnet of the Application Gateway. Don’t forget to figure out what to do with the SCM URI for DevOps/GitHub integration.

Private Endpoint

A Private Endpoint was added to the App Service. The service/subresource/serviceGroup is sites. Automatically, Microsoft will update their DNS to modify the name resolution of myapp.azurewebsites.net to resolve to myapp.privatelink.azurewebsites.net. In the above example, the NIC for the Private Endpoint gets an IP address of 10.0.64.68 from the AppSubnet that the App Service is now connected to.

Add an A record to the Private DNS Zone for the App Service, resolving to the IPv4 address of the Private Endpoint NIC. In my case, myapp.privatelink.azurewebsites.net will resolve to 10.0.64.68. This in turn means that myapp.azurewebsites.net > myapp.privatelink.azurewebsites.net > 10.0.64.68.

Application Gateway/WAF

  1. Add a new Backend Pool with the IPv4 address of the Private Endpoint NIC, which is 10.0.64.68 in my example.
  2. Create a multisite HTTPS:443 listener for the required public URI, which will be myapp.joeelway.com in my example, adding the certificate, ideally from an Azure Key Vault. Use the public IP address (in my example) as the frontend.
  3. Set up a Custom Probe to test https://myapp.azurewebsites.net:443 (using the hostname option) with acceptable responses of 200-399.
  4. Create an HTTP Setting (the reverse proxy) to forward traffic to https://myapp.azurewebsites.net:443 (using the hostname option) using a well-known certificate (accepting the default cert of the App Service) for end-to-end encryption.
  5. Bind all of the above together with a routing rule.

Public DNS

Now you need to get traffic for https://myapp.joeelway.com to go to the (public, in my example) frontend IP address of the Application Gateway/WAF. There are lots of ways to do this, including Azure Front Door, Azure Traffic Manager, and third-party solutions. The easy way is to add an A record to your public DNS zone (joeelway.com, in my example) that resolves to the public IP address of the Application Gateway.

The Result

  1. A client browses https://myapp.joeelway.com.
  2. The client name resolution goes to public DNS which resolves myapp.joeelway.com to the public IP address of the Application Gateway.
  3. The client connects to the Application Gateway, requesting https://myapp.joeelway.com.
  4. The Listener on the Application Gateway receives the connection.
    • Any WAF functionality inspects and accepts/rejects the connection request.
  5. The Routing Rule in the Application Gateway associates the request to https://myapp.joeelway.com with the HTTP Setting and Custom Probe for https://myapp.azurewebsites.net.
  6. The Application Gateway routes the request for https://myapp.joeelway.com to https://myapp.azurewebsites.net at the IPv4 address of the Private Endpoint (documented in the Application Gateway Backend Pool).
  7. The App Service receives and accepts the request for https://myapp.azurewebsites.net and responds to the Application Gateway.
  8. The Application Gateway reverse-proxies the response to the client.

For Good Measure

If you really want to secure things:

  • Deploy the Application Gateway as WAFv2 and store SSL certs in a Key Vault with limited Access Policies
  • The NSG on the WAF subnet must be configured correctly and only permit the minimum traffic to the WAF.
  • All resources will send all logs to Log Analytics.
  • Azure Sentinel is associated with the Log Analytics workspace.
  • Azure Security Center Standard Tier is enabled on the subscription and the Log Analytics Workspace.
  • If you can justify the cost, DDoS Standard Tier is enabled on the virtual network with the public IP address(es).

And that’s just the beginning 🙂

Azure Virtual WAN ARM – The Resources

In this post, I will explain the types of resources used in Azure Virtual WAN and the nature of their relationships.

Note, I have not included any content on the recently announced preview of third-party NVAs. I have not seen any materials on this yet to base such a post on and, being honest, I don’t have any use-cases for third-party NVAs.

As you can see – there are quite a few resources involved … and some that you won’t see listed at all because of the “appliance-like” nature of the deployment. I have not included any detail on spokes or “branch offices”, which would require further resources. The below diagram is enough to get a hub operational and connected to on-premises locations and spoke virtual networks.

The Virtual WAN – Microsoft.Network/virtualWans

You need at least one Virtual WAN to be deployed. This is what the hub will connect to, and you can connect many hubs to a common Virtual WAN to get automated any-to-any connectivity across the Microsoft physical WAN.

Surprisingly, the resource is deployed to an Azure region and not as a global resource, such as other global resources such as Traffic Manager or Azure DNS.

The Virtual Hub – Microsoft.Network/virtualHubs

Also known as the hub, the Virtual Hub is deployed once, and once only, per Azure region where you need a hub. This hub replaces the old hub virtual network (plus gateway(s), plus firewall, plus route tables) deployment you might be used to. The hub is deployed as a hidden resource, managed through the Virtual WAN in the Azure Portal or via scripting/ARM.

The hub is associated with the Virtual WAN through a virtualWAN property that references the resource ID of the virtualWans resource.

In a previous post, I referred to a chicken & egg scenario with the virtualHubs resource. The hub has properties that point to the resource IDs of each deployed gateway:

  • vpnGateway: For site-to-site VPN.
  • expressRouteGateway: For ExpressRoute circuit connectivity.
  • p2sVpnGateway: For end-user/device tunnels.

If you choose to deploy a “Secured Virtual Hub” there will also be a property called azureFirewall that will point to the resource ID of an Azure Firewall with the AZFW_Hub SKU.

Note, the restriction of 1 hub per Azure region does introduce a bottleneck. Under the covers of the platform, there is actually a virtual network. The only clue to this network will be in the peering properties of your spoke virtual networks. A single virtual network can have, today, a maximum of 500 spokes. So that means you will have a maximum of 500 spokes per Azure region.

Routing Tables – Microsoft.Network/virtualHubs/hubRouteTables & Microsoft.Network/virtualHubs/routeTables

These are resources that are used in custom routing, a recently announced as GA feature that won’t be live until August 3rd, according to the Azure Portal. The resource control the flows of traffic in your hub and spoke architecture. They are child-resources of the virtualHubs resource so no references of hub resource IDs are required.

Azure Firewall – Microsoft.Network/azureFirewalls

This is an optional resource that is deployed when you want a “Secured Virtual Hub”. Today, this is the only way to put a firewall into the hub, although a new preview program should make it possible for third-parties to join the hub. Alternatively, you can use custom routing to force north-south and east-west traffic through an NVA that is running in a spoke, although that will double peering costs.

The Azure Firewall is deployed with the AZFW_Hub SKU. The firewall is not a hidden resource. To manage the firewall, you must use an Azure Firewall Policy (aka Azure Firewall Manager). The firewall has a property called firewallPolicy that points to the resource ID of a firewallPolicies resource.

Azure Firewall Policy – Microsoft.Network/firewallPolicies

This is a resource that allows you to manage an Azure Firewall, in this case, an AZFW_Hub SKU of Azure Firewall. Although not shown here, you can deploy a parent/child configuration of policies to manage firewall configurations and rules in a global/local way.

VPN Gateway – Microsoft.Network/vpnGateways

This is one of 3 ways (one, two or all three at once) that you can connect on-premises (branch) sites to the hub and your Azure deployment(s). This gateway provides you with site-to-site connectivity using VPN. The VPN Gateway uses a property called virtualHub to point at the resource ID of the associated hub or virtualHubs resource. This is a hidden resource.

Note that the virtualHubs resource must also point at the resource ID of the VPN gateway resource ID using a property called vpnGateway.

ExpressRoute Gateway – Microsoft.Network/expressRouteGateways

This is one of 3 ways (one, two or all three at once) that you can connect on-premises (branch) sites to the hub and your Azure deployment(s). This gateway provides you with site-to-site connectivity using ExpressRoute. The ExpressRoute Gateway uses a property called virtualHub to point at the resource ID of the associated hub or virtualHubs resource. This is a hidden resource.

Note that the virtualHubs resource must also point at the resource ID of the ExpressRoute gateway resource ID using a property called p2sGateway.

Point-to-Site Gateway – Microsoft.Network/p2sVpnGateways

This is one of 3 ways (one, two or all three at once) that you can connect on-premises (branch) sites to the hub and your Azure deployment(s). This gateway provides users/devices with connectivity using VPN tunnels. The Point-to-Site Gateway uses a property called virtualHub to point at the resource ID of the associated hub or virtualHubs resource. This is a hidden resource.

The Point-to-Site Gateway inherits a VPN configuration from a VPN configuration resource based on Microsoft.Network/vpnServerConfigurations, referring to the configuration resource by its resource ID using a property called vpnServerConfiguration.

Note that the virtualHubs resource must also point at the resource ID of the Point-to-Site gateway resource ID using a property called p2sVpnGateway.

VPN Server Configuration – Microsoft.Network/vpnServerConfigurations

This configuration for Point-to-Site VPN gateways can be seen in the Azure WAN and is intended as a shared configuration that is reusable with more than one Point-to-Site VPN Gateway. To be honest, I can see myself using it as a per-region configuration because of some values like DNS servers and RADIUS servers that will probably be placed per-region for performance and resilience reasons. This is a hidden resource.

The following resources were added on 22nd July 2020:

VPN Sites – Microsoft.Network/vpnSites

This resource has a similar purpose to a Local Network Gateway for site-to-site VPN connections; it describes the on-premises location, AKA “branch office”.  A VPN site can be associated with one or many hubs, so it is actually connected to the Virtual WAN resource ID using a property called virtualWan. This is a hidden resource.

An array property called vpnSiteLinks describes possible connections to on-premises firewall devices.

VPN Connections – Microsoft.Network/vpnGateways/vpnConnections

A VPN Connections resource associates a VPN Gateway with the on-premises location that is described by an associated VPN Site. The vpnConnections resource is a child resource of vpnGateways, so there is no actual resource; the vpnConnections resource takes its name from the parent VPN Gateway, and the resource ID is an extension of the parent VPN Gateway resource ID.

By necessity, there is some complexity with this resource type. The remoteVpnSite property links the vpnConnections resource with the resource ID of a VPN Site resource. An array property, called vpnSiteLinkConnections, is used to connect the gateway to the on-premises location using 1 or 2 connections, each linking from vpnSiteLinkConnections to the resource/property ID of 1 or 2 vpnSiteLinks properties in the VPN Site. With one site link connection, you have a single VPN tunnel to the on-premises location. With 2 link connections, the VPN Gateway will take advantage of its active/active configuration to set up resilient tunnels to the on-premises location.

Virtual Network Connections – Microsoft.Network/virtualHubs/hubVirtualNetworkConnections

The purpose of a hub is to share resources with spoke virtual networks. In the case of the Virtual Hub, those resources are gateways, and maybe a firewall in the case of Secured Virtual Hub. As with a normal VNet-based hub & spoke, VNet peering is used. However, the way that VNet peering is used changes with the Virtual Hub; the deployment is done using the hub/VirtualNetworkConnections child resource, whose parent is the Virtual Hub. Therefore, the name and resource ID are based on the name and resource ID of the Virtual Hub resource.

The deployment is rather simple; you create a Virtual Network Connection in the hub specifying the resource ID of the spoke virtual network, using a property called remoteVirtualNetwork. The underlying resource provider will initiate both sides of the peering connection on your behalf – there is no deployment required in the spoke virtual network resource. The Virtual Network Connection will reference the Hub Route Tables in the hub to configure route association and propagation.

More Resources

There are more resources that I’ve yet to document, including:

Azure Virtual WAN ARM – The Chicken & Egg Gateway ID Discombobulation

This post will explain how to deal with the gateway ID properties in the Azure Microsoft.Network/virtualhubs resource when using ARM templates.

Background

The Azure WAN Hub is capable of having 3 gateway sub-resources:

  • Point-to-site VPN: Microsoft.Network/p2sVpnGateways
  • VPN (site-to-site): Microsoft.Network/vpnGateways
  • ExpressRoute: Microsoft.Network/expressRouteGateways, which does not support diagnostic settings in the 2020-04-01 API

As you would expect, when you create these resources, you have to supply them with the resource ID of the Microsoft.Network/virtualhubs resource:

"virtualHub": {
  "id": "<<<<resource ID of the virtual hub>>>>"
},

What is a surprise is what happens in the Microsoft.Network/virtualhubs resource. After a gateway is associated, a property (type object, presumably for future-proofing) for the associated gateway type is added to the hub:

"vpnGateway": {
  "id": "<<<< Resource ID of Microsoft.Network/vpnGateways resource>>>>"
},
"expressRouteGateway": {
 "id": "<<<< Resource ID of Microsoft.Network/p2sVpnGateways resource>>>>"
},
"p2SVpnGateway": {
 "id": "<<<< Resource ID of Microsoft.Network/expressRouteGateways resource>>>>"
},

The surprising thing is what happens.

The Problem

There are 3 possible states in the hub when it comes to each gateway:

  1. The hub exists without a gateway: The above hub properties are not required.
  2. The gateways are being added: The above hub properties cannot be added because the gateway resource ID points to a resource that does not exist yet – the hub must exist and be configured before the gateway(s).
  3. The gateways exist: Any re-run of the ARM template (which might be common to update the hub route tables or configuration via DevOps) must include the above gateway properties in the hub resource with the correct resource IDs for the gateways.

And steps 2 and 3 are where the chicken and egg are in an ARM template. You must supply the gateway resource ID in the hub for all updates to the hub after a gateway is deployed, and you must not include the gateway resource ID in the hub when deploying the gateway. This would be easy to deal with if ARM would (finally) give us a “ifexists()” function but there is no sign of that. So we need a hack solution.

The Hack Solution

This one comes from the Well-Architected Framework/Cloud Adoption Framework, Enterprise-Scale Architecture. This way-too-complicated beastie shows how Microsoft’s people are dealing with the issue. The JSON for the Microsoft.Network/virtualhubs template contains these properties:

"properties": {
  "virtualWan": {
    "id": "[variables('vwanresourceid')]"
  },
  "addressPrefix": "[parameters('vHUB').addressPrefix]",
  "vpnGateway": "[if(not(empty(parameters('vHUB').vpnGateway)),parameters('vHUB').vpnGateway, json('null'))]"
}

The key for dealing with vpnGateway is the vHUB parameter, an object that contains a value called vpnGateway.

When they first run the deployment, the value of vHUB.vpngateway is set to {} or null in the parameters file, stored in GitHub. That means that when the hub is first run (and there is no VPN gateway), the if statement in the above snippet will pass json(‘null’) to the vpnGateway property. That is acceptable to the resource provider and the hub will deploy cleanly. Later on in the deployment, the VPN gateway will be created.

If you were to just re-run the hub template now, you will get an error about not being allowed to change the vpnGateway property in the hub resource. Behind the scenes it has been updated by the VPN gateway deployment. Every execution of the hub template must now include the resource ID of the VPN Gateway – that sucks, right? Now the hack really kicks in.

After the first deployment of the hub (and the VPN Gateway), you must open the resource group in the Azure Portal, enable viewing hidden items, open the VPN Gateway resource, go to properties, and document the resource ID.

Now, you need to open the parameters file for the hub. Edit the vHUB.vpnGateway property and set it to:

"vpnGateway": {
 "id": "<<<< Resource ID of Microsoft.Network/vpnGateways resource>>>>"
},

Now you can cleanly re-run the hub template.

How Should It Work?

The best solution would be if the gateway ID properties were just documentation for Azure, properties that we humans cannot edit. But I suspect that the ability to configure these settings might have something to do with the newly announced NVA-in-hub preview. Otherwise, ARM needs to finally give us an ifexists() function – vote here now if you agree.

Azure Virtual WAN ARM – Secured Virtual Hub Azure Firewall

I have spent quite a few hours figuring out how to deploy Azure’s new Secured Virtual Hub, an extension of Azure Virtual WAN, deployed using ARM templates (JSON). A lot of the bits are either not documented or incorrectly documented. One of the frustrating bits to deploy was the Azure Firewall resource – and the online examples did not help.

The issue was that the 2 sources I could find did not include public IP addresses on the firewall:

  • The quick start for Secured Virtual Hub on docs.microsoft.com
  • The new Enterprise-Scale “well-architected” Framework, found in Cloud Adoption Framework

Digging to solve that uncovered:

  • The examples used quite an old API version, 2019-08-01, to deploy the Microsoft.Network/azureFirewalls resource.
  • There was no example of how to add a public IP address to the firewall in Secured Virtual Hub because it was not possible with that API – SVH is quite different from a VNet deployment because you do have direct access to the underlying hub virtual network.
  • Being an old API, we lose features such as SNAT for non-RFC1918 addresses (important in universities and public sector) and the newer custom & proxy DNS features.

In my digging, I did uncover that the ARM reference for the Azure Firewall was incorrect, but I did uncover a new, barely-documented property called hubIPAddresses; I knew this property was the key to solving the public IP address issue. So I thought about what was going on and how I was going to solve it.

I ended up doing what I would normally do if I did not have a quick start template to start with:

  1. Deploy the resource(s) by hand in the Azure Portal
  2. Observe the options – there was a slide control for the quantity of firewall public IP addresses
  3. Export the resulting template

And … there was the solution:

  1. There is a new, undocumented API version for the Azure Firewall resource: 2020-05-01
  2. There is a new object property called hubIPAddresses that contains an object sub-property called publicIps. You can set a string value called count to control how many public IP addresses that Azure will assign (on your behalf) to the firewall – you do not need to create the public IP address resources.
        "hubIPAddresses": {
          "publicIPs": {
            "count": "[parameters('firewallPublicIpQuantity')]",
          }
        }

Sorted!

Azure Virtual WAN Introducing A New Kind Of Route Table

In this post, I will quickly introduce you to a new kind of Route Table in Microsoft Azure that has been recently introduced by Azure Virtual WAN – and hence is included in the newly generally available Secured Virtual Hub.

The Old “Subnet” Route Table

This Route Table, which I will call “Subnet Route Table” (derived from the ARM name) is a simple resource that we associate with a subnet. It contains User-Defined Routes that force traffic to flow in desirable directions, typically when we use some kind of firewall appliance (Azure Firewall or third-party) or a third-party routing appliance. route The design is simple enough:

  • Name: A user-friendly name
  • Prefix: The CIDR you want to get to
  • Next Hop Type: What kind of “router” is the next hop, e.g. Virtual Network, Internet, or Virtual Appliance
  • Next Hop IP Address: Used when Next Hop Type is Virtual Appliance (any firewall or third-party router)

Azure Virtual WAN Hub

Microsoft introduced Azure Virtual WAN quite a while ago (by Cloud standards), but few still have heard of it, possibly because of how it was originally marketed as an SD-WAN solution compatible originally with just a few on-prem SD-WAN vendors (now a much bigger list). Today it supports IKEv1 and IKEv2 site-to-site VPN, point-to-site VPN, and ExpressRoute Standard (and higher). You might already be familiar with setting up a hub in a hub-and-spoke: you have to create the virtual network, the Route Table for inbound traffic, the firewall, etc. Azure Virtual WAN converts the hub into an appliance-like experience surfacing just two resources: the Virtual WAN (typically 1 global resource per organisation) and the hub (one per Azure region). Peering, routing, connectivity are all simplified.

A more recent change has been the Secured Virtual Hub, where Azure Firewall is a part of the Virtual WAN Hub; this was announced at Ignite and has just gone GA. Choosing the Secured Virtual Hub option adds security to the Virtual WAN Hub. Don’t worry, though, if you prefer a third-party firewall; the new routing model in Azure Virtual WAN Hub allows you to deploy your firewall into a dedicated spoke virtual network and route your isolated traffic through there.

The New Route Tables

There are two new kinds of route table added by the Virtual WAN Hub, or Virtual Hub, both of which are created in the Virtual Hub as sub-resources.

  • Virtual Wan Hub Route Table
  • Virtual WAN Route Table

Virtual WAN Hub Route Table

The Virtual Hub Hub Route Table affects traffic from the Virtual Hub to other locations.  A possible scenario is when you want to route traffic to a CIDR block of virtual network(s) through a third-party firewall (network virtual appliance/NVA):

AzureVirtualWanHubHubRouteTable

The routing rule setup here is similar to the Subnet Route Table, specifying where you want to get to (CIDR, resource ID, or service), the next hop, and a next hop IP address.

Virtual WAN Route Table

The Virtual WAN Route Table is created as a sub resource of the Virtual Hub but it has a different purpose. The Virtual Hub is assigned to connections and affects routing from the associated branch offices or virtual networks. Whoa, Finn! There is a lot of terminology in that sentence!

A connection is just that; it is a connection between the hub and another network. Each spoke connected directly to the hub has a connection to the hub – a Virtual WAN Route Table can be associated with each connection. A Virtual WAN Route Table can be associated with 1 virtual network connection, a subset of them, or all of them.

The term “branch offices” refers to sites connected by ExpressRoute, site-to-site VPN, or point-to-site VPN. Those sites also have connections that a Virtual WAN Route Table can be associated with.

This is a much more interesting form of route table. I haven’t had time to fully get under the covers here, but comparing ARM to the UI reveals two methodologies. The Azure Portal reveals one way of visualising routing that I must admit that I find difficult to scale in my mind. The ARM resource looks much more familiar to me, but until I get into a lab and fully test (which I hope I will find some hours to do soon), I cannot completely document.

Here are the basics of what I have gleaned from the documentation, which covers the Azure Portal method:

The linked documentation is heavy reading. I’m one of those people that needs to play with this stuff before writing too much in detail – I never trust the docs and, to be honest, this content is complicated, as you can see above.

Connecting Azure Hub-And-Spoke Architectures Together

In this post, I will explain how you can connect multiple Azure hub-and-spoke (virtual data centre) deployments together using Azure networking, even across different Azure regions.

There is a lot to know here so here is some recommended reading that I previously published:

If you are using Azure Virtual WAN Hub then some stuff will be different and that scenario is not covered fully here – Azure Virtual WAN Hub has a preview (today) feature for Any-to-Any routing.

The Scenario

In this case, there are two hub-and-spoke deployments:

  • Blue: Multiple virtual networks covered by the CIDR of 10.1.0.0/16
  • Green: Another set of multiple virtual networks covered by the CIDR of 10.2.0.0/16

I’m being strategic with the addressing of each hub-and-spoke deployment, ensuring that a single CIDR will include the hub and all spokes of a single deployment – this will come in handy when we look at User-Defined Routes.

Either of these hub-and-spoke deployments could be in the same region or even in different Azure regions. It is desired that if:

  • Any spoke wishes to talk to another spoke it will route through the local firewall in the local hub.
  • All traffic coming into a spoke from an outside source, such as the other hub-and-spoke, must route through the local firewall in the local hub.

That would mean that Spoke 1 must route through Hub 1 and then Hub 2 to talk to Spoke 4. The firewall can be a third-party appliance or the Azure Firewall.

Core Routing

Each subnet in each spoke needs a route to the outside world (0.0.0.0/0) via the local firewall. For example:

  • The Blue firewall backend/private IP address is 10.1.0.132
  • A Route Table for each subnet is created in the Blue deployment and has a route to 0.0.0.0/0 via a virtual appliance with an IP address of 10.1.0.132
  • The Greenfirewall backend/private IP address is 10.2.0.132
  • A Route Table for each subnet is created in the Green deployment and has a route to 0.0.0.0/0 via a virtual appliance with an IP address of 10.2.0.132

Note: Some network-connected PaaS services, e.g. API Management or SQL Managed Instance, require additional routes to the “control plane” that will bypass the local firewall.

Site-to-Site VPN

In this scenario, the organisation is connecting on-premises networks to 1 or more of the hub-and-spoke deployments with a site-to-site VPN connection. That connection goes to the hub of Blue and to Green hubs.

To connect Blue and Green you will need to configure VNet Peering, which can work inside a region or across regions (using Microsoft’s low latency WAN, the second-largest private WAN on the planet). Each end of peering needs the following settings (the names of the settings change so I’m not checking their exact naming):

  • Enabled: Yes
  • Allow Transit: Yes
  • Use Remote Gateway: No
  • Allow Gateway Sharing: No

Let’s go back and do some routing theory!

That peering connection will add a hidden Default (“system”) route to each subnet in the hub subnets:

  • Blue hub subnets: A route to 10.2.0.0/24
  • Green hub subnets: A route to 10.1.0.0/24

Now imagine you are a packet in Spoke 1 trying to get to Spoke 4. You’re sent to the firewall in Blue Hub 1. The firewall lets the traffic out (if a rule allows it) and now the packet sits in the egress/frontend/firewall subnet and is trying to find a route to 10.2.2.0/24. The peering-created Default route covers 10.2.0.0/24 but not the subnet for Spoke 4. So that means the default route to 0.0.0.0/0 (Internet) will be used and the packet is lost.

To fix this you will need to add a Route Table to the egress/frontend/firewall subnet in each hub:

  • Blue firewall subnet Route Table: 10.2.0.0/16 via virtual appliance 10.2.0.132
  • Red firewall subnet Route Table: 10.1.0.0/16 via virtual appliance 10.1.0.132

Thanks to my clever addressing of each hub-and-spoke, a single route will cover all packets leaving Blue and trying to get to any spoke in Red and vice-versa.

ExpressRoute

Now the customer has decided to use ExpressRoute to connect to Azure – Sweet! But guess what – you don’t need 1 expensive circuit to each hub-and-spoke.

You can share a single circuit across multiple ExpressRoute gateways:

  • ExpressRoute Standard: Up to 10 simultaneous connections to Virtual Network Gateways in 1+ regions in the same geopolitical region.
  • ExpressRoute Premium: Up to 100 simultaneous connections to Virtual Network Gateways in 1+ regions in any geopolitical region.

FYI, ExpressRoute connections to the Azure Virtual WAN Hub must be of the Premium SKU.

ExpressRoute is powered by BGP. All the on-premises routes that are advertised propagate through the ISP to the Microsoft edge router (“meet-me”) in the edge data centre. For example, if I want an ExpressRoute circuit to Azure West Europe (Middenmeer, Netherlands – not Amsterdam) I will probably (not always) get a circuit to the POP or edge data centre in Amsterdam. That gets me a physical low-latency connection onto the Microsoft WAN – and my BGP routes get to the meet-me router in Amsterdam. Now I can route to locations on that WAN. If I connect a VNet Gateway to that circuit to Blue in Azure West Europe, then my BGP routes will propagate from the meet-me router to the GatewaySubnet in the Blue hub, and then on to my firewall subnet.

BGP propagation is disabled in the spoke Route Tables to ensure all outbound flows go through the local firewall.

But that is not the extent of things! The hub-and-spoke peering connections allow Gateway Sharing from the hub and Use Remote Gateway from the spoke. With that configuration, BGP routes to the spoke get propagated to the GatewaySubnet in the hub, then to the meet-me router, through the ISP and then to the on-premises network. This is what our solution is based on.

Let’s imagine that the Green deployment is in North Europe (Dublin, Ireland). I could get a second ExpressRoute connection but:

  • That will add cost
  • Not give me the clever solution that I want – but I could work around that with ExpressRoute Global Reach

I’m going to keep this simple – by the way, if I wanted Green to be in a different geopolitical region such as East US 2 then I could use ExpressRoute Premium to make this work.

In the Green hub, the Virtual Network Gateway will connect to the existing ExpressRoute circuit – no more money to the ISP! That means Green will connect to the same meet-me router as Blue. The on-premises routes will get into Green the exact same way as with Blue. And the routes to the Green spokes will also propagate down to on-premises via the meet-me router. That meet-me router knows all about the subnets in Blue and Green. And guess what BGP routers do? They propagate – so, the routes to all of the Blue subnets propagate to Green and vice-versa with the next hop (after the Virtual Network Gateway) being the meet-me router. There are no Route Tables or peering required in the hubs – it just works!

Now the path from Blue Spoke 1 to Green Spoke 4 is Blue Hub Firewall, Blue Virtual Network Gateway, <the Microsoft WAN>, Microsoft (meet-me) Router, <the Microsoft WAN>, Green Virtual Network Gateway, Green Hub Firewall, Green Spoke 4.

There are ways to make this scenario more interesting. Let’s say I have an office in London and I want to use Microsoft Azure. Some stuff will reside in UK South for compliance or performance reasons. But UK South is not a “hero region” as Microsoft calls them. There might be more advanced features that I want to use that are only in West Europe. I could use two ExpressRoute circuits, one to UK South and one to West Europe. Or I could set up a single circuit to London to get me onto the Microsoft WAN and connected this circuit to both of my deployments in UK South and West Europe. I have a quicker route going Office > ISP > London edge data center > Azure West Europe than from Office > ISP > Amsterdam edge data center > Azure West Europe because I have reduced the latency between me and West Europe by reducing the length of the ISP circuit and using the more-direct Microsoft WAN. Just like with Azure Front Door, you want to get onto the Microsoft WAN as quickly as possible and let it get you to your destination as quickly as possible.
